    Antistatic PVC Floor Tiles Conductive Vinyl Flooring | ESD and Antistatic Solution

    Ask Lasest Price
    Brand Name : None
    Model Number : HZ-F01
    Certification : Rohs, CE
    Price : 6usd/m2
    Payment Terms : T/T, D/P,
    Delivery Time : 5-7 work days
    • Product Details
    • Company Profile

    Antistatic PVC Floor Tiles Conductive Vinyl Flooring | ESD and Antistatic Solution

    Description of Conductive Floor Tiles:

    The anti-static pvc floor is made up of various materials, including carbon fibers, which will pass the electrostatic charge to the Floor to reduce the risk of a static discharge from physical contact.
    It is used to shield devices and other objects from damage caused by static electricity accumulated in the workplace.


    Size Spec:


    Sheet size: 600mm*600mm/900mm*900mm
    Roll size: 2m*20m/Roll

    Thickness: 2.0mm/3.0mm (2.5mm customized)



    PVC flooring features two main characteristics: stain resistance and easy cleaning.

    Stain resistance is achieved through seamless interlocking and PUR surface treatment.
    Various stains on PVC flooring do not penetrate the floor, preventing dirt residue and odors.


    ItemStandardIndex
    SizeEN426600*600mm
    900*900mm
    ThicknessEN4282.0, 2.5, 3.0mm
    WeightEN4302.0mm, 3.8kgs/m3
    2.5mm, 4.8/kgs/m3
    3.0mm, 5.8/kgs/m3
    Surface RresistanceDIN51953104-106 Ω Conductive
    ASTMF-1550 or NFPA99106-109 Ω Dissipative
    Decay TimeSJ/T10694-2006(VI<100V)Equal 0.4S
    Charge VoltageSJ/T10694-2006(VI<100V)Equal 70
    Fire ResistanceDIN 4102B1
    Combustion PropertiesSJ/T11236-2001(<10s,FV-0)Equal 0.35s Ifv-0
    Amount of anti-wearSJ/T11236-2001(less than 0.02g/cm3, 110r)Equal 0.014
    Anti-wear PropertiesEN660pt2Ten-T < 2.0 mm3
    Wheel PressureEN425No influence
    Residual ConcavityEN433, DIN519550.03mm(2.0mm)
    0.035mm(2.5mm)
    0.04mm(3mm)
    Dimensional stabilityEN434Less than 0.1%
    Color fastnessIDO105BO2At least 6
    Resistance to chenmicalsDIN423,DIN51958offers excellent resistance ask for special sheet
