SMT PCB ESD Magazine Rack Gear Adjustable Magazine Rack for PCB Storage

A PCB Magazine or PCB Rack is made of volume conductive polypropylene and metal, which is used to transport the PCB boards for automated assembly lines.

The anti-static PCB magazines racks are an ideal aid in the production, storage and transportation of PCBs.

The strong and robust polypropylene sidewall and metal frame guarantee that these PCB magazines racks are durable, which last very long time.

Size Chart:

Model	Outer size(mm)	PCB plate size(mm)	Base material	Adjust type	Temp.	Slots	Weight (KG)
HZ-2601	355315580	355*(80-250)	Plastic	Screw adjust.	80℃	50	5
HZ-2602	355315305	355*(80-250)	Plastic	Screw adjust.	80℃	25	3.4
HZ-2603	355320563	355* (50-250)	Metal	Screw / gear track	80℃/120℃/200℃	50	5
HZ-2604	355320563	355* (50-250)	Plastic	Gear track	80℃/120℃	50	4.5
HZ-2605	355320563	355* (50-250)	Metal	Screw / gear track	80℃/120℃	50	6.5
HZ-2606	355320563	355* (50-250)	Metal	Gear track	80℃/120℃	50	6
HZ-2607	460400563	460*(50-330)	Metal	Screw / gear track	80℃/120℃/200℃	50	8
HZ-2608	535460570	535*(50-390)	Metal	Screw / gear track	80℃/120℃	50	10.5
HZ-2609	535530570	535*(120-460)	Metal	Screw / gear track	80℃/120℃	50	12
HZ-2610	630530570	630*(50-460)	Metal	Screw adjust.	80℃	50	13
HZ-2611	355320560	355* (50-250)	Plastic	Chain adjust.	80℃	50	6
HZ-2612	355320560	355*(80-250)	Metal	Screw / gear track	550℃	50	6.8
HZ-2613	400320563	400*(50-250)	Metal	Screw / gear track	80℃	50	6

Product Description: SMT ESD PCB Magazine Rack
EQUIPMENT AND PRODUCTS FOR THE ESD PRODUCTION LINE
PCB Magazine
ESD PCB Magazine Rack
SMT PCB Magazine Rack
SMT ESD PCB Magazine

ESD SMT PCB Magazine Racks:

A PCB Magazine or PCB Rack is made of volume conductive polypropyleneand metalwhich is used to transport the PCB boards for automated assembly lines

1.The SMT magazine rack is designed for PCBs manufacture, assembly, storage and transfer.

2.Adjustable through screws,gear adjustment.

3.Common type (60°C) and heat-resistance type(120°C ,160~200°C) are available.

4.Surface resistance: 104~106 ohm.

5.Base: P-Conductive PS, M-Zincification Iron

6.Adjustment: G-Gear track adjustment, S-Screw adjustment

7.Max tolerant temperature: 60°C,120°C,160~200°C different material 8.PCB slots:The number of the SMT magazine rack Can accommodate PCBs

Packing and Shipping:
