Anti Slip ESD Rubber Mat / Clean Room Anti Fatigue Mats Thickness 18-22mm

Product Categories

Shanghai Herzesd Industrial Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: Anti Slip ESD Rubber Mat Clean Room Anti Fatigue Mats Thickness 1822mm
Brand: Herzesd
Price: 60 USD

Add to Cart

3 layers structure, surface is pvc, middle layer is EPDM foam, bottom layer is conductive rubber.
Size(mm): 610x910x20, 610x450x20, other size can be customized.
Surface resistance: RTT 1x10E8-10E9 ohms
Fit for electronic components manufacturers and static sensitive area.

Model	Size(mm)	Material	Surface Resistance	Ground Resistance	Anti-fatigue Effect	Note
HZ-950	610x460x15	Good Natural Rubber	<10⁷ohm	<10⁷ohm	Best
HZ-930	610x910x12.5 610x450x12.5	Rubber Material	10⁸-10⁹ohm	10⁸-10⁹ohm	Good	Low cost design
HZ-418S	610x910x17	2 layers: PVC+ Carbamic resin	10⁸-10⁹ohm	10⁹-10¹⁰ohm	Better
HZ-418E	610x910x18 610x450x18	3 layers: PVC + Carbamic resin + Conductive rubber.	10⁸-10⁹ohm	10⁹-10¹⁰ohm	Better
HZ-418B	610x910x20	3 layers: PVC + EPDM + Conductive rubber.	10⁸-10⁹ohm	10⁹-10¹⁰ohm	Better	Low cost design

Anti Slip ESD Rubber Mat / Clean Room Anti Fatigue Mats Thickness 18-22mm
