ESD Magazine Rack
A PCB Magazine or PCB Rack is made of volume conductive
polypropylene and metal, which is used to transport the PCB boards
for automated assembly lines. The anti-static PCB magazine racks
are an ideal aid in the production, storage, and transportation of
PCBs. The robust sidewall and metal frame guarantee that these PCB
magazine racks are durable, and last a very long time.
1. The SMT magazine rack is designed for PCB manufacture, assembly,
storage, and transfer.
2. Adjustable through screws, gear adjustment.
3. Common type (60°C) and heat-resistance type(120°C ,160~200°C)
are available.
4. Surface resistance: 104~106 ohm.
5. Base: P-Conductive PS, M-Zincification Iron
6. Adjustment: G-Gear track adjustment, S-Screw adjustment
7. Max tolerant temperature: 60°C,120°C,160~200°C different
material
8. PCB slots: The number of the SMT magazine rack Can accommodate
PCBs
Product Description
Customization
| Model | Outer size(mm) | PCB plate size(mm) | Base material | Adjust type | Temp. | Slots | Weight
(KG) |
| HZ-2601 | 355*315*580 | 355*(80-250) | Plastic | Screw adjust. | 80℃ | 50 | 5 |
| HZ-2602 | 355*315*305 | 355*(80-250) | Plastic | Screw adjust. | 80℃ | 25 | 3.4 |
| HZ-2603 | 355*320*563 | 355* (50-250) | Metal | Screw/gear track | 80℃/120℃/200℃ | 50 | 5 |
| HZ-2604 | 355*320*563 | 355* (50-250) | Plastic | Gear track | 80℃/120℃ | 50 | 4.5 |
| HZ-2605 | 355*320*563 | 355* (50-250) | Metal | Screw/gear track | 80℃/120℃ | 50 | 6.5 |
| HZ-2606 | 355*320*563 | 355* (50-250) | Metal | Gear track | 80℃/120℃ | 50 | 6 |
| HZ-2607 | 460*400*563 | 460*(50-330) | Metal | Screw/gear track | 80℃/120℃/200℃ | 50 | 8 |
| HZ-2608 | 535*460*570 | 535*(50-390) | Metal | Screw/gear track | 80℃/120℃ | 50 | 10.5 |
| HZ-2609 | 535*530*570 | 535*(120-460) | Metal | Screw/gear track | 80℃/120℃ | 50 | 12 |
| HZ-2610 | 630*530*570 | 630*(50-460) | Metal | Screw adjust. | 80℃ | 50 | 13 |
| HZ-2611 | 355*320*560 | 355* (50-250) | Plastic | Chain adjust. | 80℃ | 50 | 6 |
| HZ-2612 | 355*320*560 | 355*(80-250) | Metal | Screw/gear track | 550℃ | 50 | 6.8 |
| HZ-2613 | 400*320*563 | 400*(50-250) | Metal | Screw/gear track | 80℃ | 50 | 6 |
Company Profile
Shanghai Herzesd Industry Co., Ltd
Specialized range of ESD products including anti-static equipment,
ESD Work Station Accessories, Safe Packaging Materials, ESD Control
Materials, etc.
In today's cutting-edge competition of electronic products,
Shanghai Herzesd Industry Co., Ltd enjoys a high reputation amongst
customers due to its excellent product quality, reasonable price
range, and top-class professional services. Established in the year
2018, we are a reputed manufacturer, supplier, exporter, and trader
of ESD Products which include ESD Equipments, Anti-static
Equipments, ESD Work Station Accessories, ESD Shielding bags, ESD
Magazine Racks, ESD PCB trolleys, ESD Workstation, ESD Garments,
ESD Fabrics, Safe Packaging Materials, ESD Control Materials,
Static Control Equipments, etc.
Packaging & Shipping
ESD Magazine Rack will be packaged in a cardboard box with foam
cushioning to ensure safety during transit.
The box will be marked with the name of the product, shipping
address, and other relevant shipping information.
The package will be shipped to the customer’s address via a
reliable courier service.
FAQ
Q:1. Why do you need ESD protection for your production line?
♦ Electronic Components or assemblies at risk from electrostatic
discharges (ESD) are among those sensitive elements that can be
destroyed or damaged if the permitted levels of current or impact
energy are exceeded.
♦ As a rule, these are always semi-conducting components and most
are also thick- and thin-film construction elements. This type of
construction element is mostly damaged through human mishandling. A
human being can charge several thousands of volts just by walking.
A discharge can be felt by humans from approximately 2000-3000 V, a
current which is already well above the 'tolerance level' of many
ESD components.
♦ Before buying or implementing ESD-safe products one needs to
implement an ESD-safe procedure according to the ESD standards IEC
61340 or ANSI S2020 which is the foundation of ESD preventive
protective work and a greater guarantee of quality assurance.
♦ Besides our Anti-Static conductive ESD Workstations we offer an
extensive range of
Antistatic ESD Chairs, Antistatic ESD Cleaning & Maintenance,
Antistatic ESD Clothing, ESD Shoes ESD Footwear, Antistatic ESD
Flooring & Antistatic ESD Table Mats, ESD Safe Packaging, ESD
Personal Grounding Materials, Anti-Static ESD Protective Storage &
Warehousing Systems EPA, ESD Storage Boxes, ESD Test & Measuring
Equipment, ESD Training, ESD Support & ESD Audits.
Q: 2. Why did you choose HerzESD?
♦ HerzESD strives to serve our customers better by offering correct
and clear explanatory answers. We try to do so, even when informing
our customers better, which means contradicting a more established
but sometimes flawed opinion on the market. At HerzESD we pride
ourselves on ensuring the only correct ESD solution.
♦ To continue this vision we need reliable ESD manufacturers and
suppliers on which we can always count. HerzESD is a solid partner
and together with our international partners, we stay strong and
vigilant in regards to possible improvements or new solutions in
tackling and controlling static electricity.
